Hydropneumatic suspension fork (air/oil) with automatic lockout, rebound adjustment, and positive air chamber pressure adjustment.
DESCRIPTION
Grap is the world's first suspension fork for Gravel with automatic lockout system!
This system is ideal for the ride style, as the rider does not have to worry about locking and unlocking the suspension, when riding on regular terrain the suspension will be firm and when going through uneven terrain the suspension will dampen impacts without the need for any effort from the rider.
In addition to the SVI automatic lockout system, Grap features rebound adjustment, positive air chamber pressure adjustment and air chamber reducers to change the travel limit, customizing it for your preference.
Grap is an excellent option for you to improve comfort, safety and performance in your Gravel pedals.
GREEN MOSS OR SAND
with satin paint
MATTE BLACK
with reflective decals
TECHNICAL SPECIFICATION
RIDING STYLE
Gravel
DAMPING SYSTEM
Air/Oil
V-AIR
Positive air chamber pressure adjustment
Air chamber adjustment with 4 chamber reducers
SVI
Automatic lockout adjustment
Rebound adjustment
STRUCTURE
LOWER LEG
Magnesium alloy
CROWN
Forged high-strength aluminum alloy
UPPER TUBES
32 mm diameter machined high-strength aluminum alloy with black hard
anodizing – Ahd
CONFIGURATIONS
WHEEL SIZE
700c
27.5
AXLE
9 x 100 mm
12 x 100 mm
12 x 100 mm
STEERER
Over 1.1/8″
Tapered 1.1/8” – 1.5”
Tapered 1.1/8” – 1.5”
TRAVEL
30 mm
40 mm
40 mm
BRAKE
Post mount – direct mount for 160 mm disc
Flat mount – mount with adapter supplied with suspension for 180 mm disc
Flat mount – mount with adapter supplied with suspension for 180 mm disc
WEIGHT
1750 g
DIMENSIONS
STEERER
250 mm – Over steerer
250 mm – Tapered steerer
FORK OFFSET
44 mm – Over steerer
47 mm – Tapered steerer
AXLE-CROWN
435 mm – 30 mm travel
445 mm – 40 mm travel
RECOMMENDED LIMITS
MAXIMUM TIRE WIDTH
700 x 50 mm
27.5 x 2.1
MAXIMUM ROTOR SIZE
180 mm
RIDER MAXIMUM WEIGHT
100 kg
FEATURES
COLORS
Matte Black, Sand, Moss Green
OTHER
Dark Grey anodized Top Caps
Exclusive ProShock reflective glossy black decals in matte black suspensions
OPTIONAL
(sold separately)
OPTIONAL
(sold separately)
TOP CAPS
Anodized Top Caps in colors: Red, Green, Blue, Orange, Gold, Pink, Purple, Turquoise, Smoke and Black
TECHNOLOGIES
A system with a positive air chamber and a coil negative spring, which provides the biker with comfort and good performance while allowing easy adjustment.
